Downspout roll forming machine

Downspout roll forming machine is the role of downspout products that collect rainwater from roofs, and then the downspout produced by downspout machine usually flows rainwater into underground pipes, such process is just for water treatment, and the visible downspout work is very simple. Our downpipe forming machine mainly consists of uncoiler, forming system, cutting equipment, shrink device, hydraulic system, control system and work table. The downpipe can be made to form a curve to meet the requirements of the actual project.

Pipe thickness of gutter could be 0.4mm-0.6mm, 0.8-1.5mm or as you asked with raw material: Aluminum, Galvanized steel, Painted steel, Galvalume, Stainless steel and Cooper etc. We could offer you square pipe roll forming machine (rectangular downspouts roll forming machine) and round pipe roll forming machine (round corrugated downspouts roll forming machine) and pipe elbow machine. Machinable size depends on your profile drawing.
Downspout roll forming machine has been exported to Serbia,Russia, Australia, Philippines, Vietnam and Mexico.

Round pipe sizes:40mm、 50 mm、75 mm、90mm 、110mm 、150 mm、200 mm、250 mm、315 mm、400 mm、500 mm.

Square pipe sizes:80mm*55mm、80mm*63mm、80mm*100mm、130mm*100mm、144mm*108mm.


Flow chat

1.Uncoiler→feeding→Roll forming→Cutting→Curving→Out table



Downspout roll forming machine
1 Forming station Normally 20-24stations or more.according to customer drawing to design.
2 Machine structure Chain drive or gearbox drive.
3 Speed 0-20m/min.
4 Cutting Hydraulic pst cutting or Fly saw cutting.
5 Out table Manual or automatic.
6 Computer control system(PLC) Panasonic or Simens.
7 Roller material GCr15,Cr12,SKD11 quenching treatment:HRC58-62(optional).
8 Structure Wall panel style or Torri stand.
10 Raw material request: Thickness:0.4-0.6mm,1.6-2.0mm PPGI,copper,galvanized steel,Galvalume.
11 Shaft of diameter Φ70mm quenching treatment (Harbin bearing).
12 Downspout Round pipe and square pipe,we can bending,shrink,curving the pipe after roll forming machine.

Customer case

Downspout roll forming machine sold to Kazakhstan.

Downspout roll forming machine sold to Serbia.

Downspout roll forming machine sold to Africa.

Machine components pictures
